2-Way Audio Surveillance Camera TL-SC3130
CAMERA
Image Sensor 1/4" Progressive scan CMOS sensor
Lens F: 2.0, f: 4.0mm
Viewing Angle Diagonal 67°, Horizontal 53°, Vertical 40°
Digital Zoom 10x Digital
Minimum Illumination 0.5 Lux
VIDEO/IMAGE
Video Compression Motion JPEG; MPEG-4
Frame Rate & Resolutions Up to 30(NTSC) / 25(PAL) fps at 640x480, 320x240, 160x120
Video Streaming Simultaneous Motion JPEG and MPEG-4 (Dual streaming)
Image Settings Rotation: Mirror, Flip, Mirror Flip
brightness, contrast, saturation, hue
Overlay capabilities:
time, date, text and privacy image
AUDIO
Audio Communication Two-way (full duplex)
Audio Input Built-in microphone
Audio Output Audio line output connector for external speaker
Audio Compression G.711 PCM, 8 kHz, 64 kbit/s
ALARM AND EVENT MANAGEMENT
Events Trigger Built-in motion detection, schedule
Notification Method E-mail, FTP, HTTP
NETWORK
Standards and Protocols Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP,
DNS, NTP, UPnP, RTSP, RTP, RTCP, HTTP, TCP,UDP,
3GPP/ISMA RTSP
Security Multiple user access levels with password protection, HTTPS encryption
INTERFACES
Network Interface 1 RJ- 45 for Ethernet 10/100 Base-T
Power Connector DC power jack
Audio Output 3.5 mm jack for Speaker out
Button Reset push button
SURVEILLANCE MANAGEMENT
Users 5 simultaneous users
Unlimited number of users using multicast
Bundled Management Software Viewing and recording up to 16 cameras
MINIMUM SYSTEM REQUIREMENTS
CPU Pentium4 1.8GHz (or equivalent AMD)
Graphic Card 64MB RAM graphic cards (or equivalent on-board graphic cards)
Memory 512MB RAM
Supported Browser Internet Explorer; Firefox; Chrome; Safari
Supported OS Windows 98/ME/2000/2003/XP/Vista/7, Mac OS Leopard 10.5
GENERAL
External Power Supply 5VDC, Max 3W
Certification CE, FCC, RoHS
Package Contents 2-Way Audio Surveillance Camera TL-SC3130
Camera Stand
1 Detachable Omni-directional Antenna
Power Adapter
RJ-45 Ethernet Cable
Quick Installation Guide
Resource CD
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Dimensions( H X W X D ) 3.7 x 2 .7 x 1.2 in. (96 x 58 x 31mm)
